740 Portable Suspended Solids Monitor
General Specification
Physical
Dimensions (hxwxd)
Monitor 224 x 106 x 39 mm
Sensor 45 mm Diameter 155 mm long
Weight
Monitor 0.5 kg
Sensor 0.6 kg (inc 5 metres of cable)
Protection Class
Electronics IP65
Sensor IP68
Enclosure Material
Monitor ABS
Sensor Black Acetal Co-Polymer
Bag Nylon
Cable Entry
Plug for Sensor and Charger
Cable Size
5 mm OD
Cable Length
5 metres standard 100 metres maximum
Electrical
Power Supply
Rechargeable battery
Charger
90-264 VAC UK US EU and Australian plug style
Optional Car Charger available
Environmental Data
Operating Temperature
Monitor -20 to 60C
Sensor 0-60C
Storage Temperature
-20 to 60C
Location
Indoor Outdoor Portable
User Interface
Display
Graphical Display providing 4 1 2 Digits with 2 message lines
Setup
via 6 button keypad
Units of Measurement
mg l g l ppm NTU FTU SS
Measurement Specification
Measurement Characteristics
Principal of Operation
Light Attenuation
Wavelength
960 nm Infrared
Accuracy
- 5 of reading or 10mg l whichever is greater
Repeatability
- 1 FSD
Response Time
0.5 seconds display damping available
Sensor Ranges
Soli-Tech 10
Range 0-20000 mg l auto-ranging
Order Information
Part Number
Description
225835
740 Monitor c w Soli-Tech 10 Sensor (Cable Length 5 metres) and Mains Charger (Multi-Country Plug UK US EU AU)
225838
740 Monitor c w Soli-Tech 10 Sensor (Cable Length 10 metres) and Mains Charger (Multi-Country Plug UK US EU AU)
222220
740 Monitor c w Soli-Tech 10 Sensor (Cable Length 10 metres) and Car Charger
Accessory
203230
Car Power Supply
