Intrinsically Safe Portable Density Meters DMA 35 Ex and Ex Petrol
Technical Specifications
DMA 35 Version DMA 35 Ex DMA 35 Ex Petrol
Measuring range Density 0 g cmto 3 g cm
Temperature 00C to 40C (32F to 104F)
Viscosity 0 mPa s to 1000 mPa s
Accuracy Density 0.001 g cm
Temperature 0.2C (0.4F)
Repeatability s.d. Density 0.0005g cm
Temperature 0.1C (0.2F)
Ambient temperature -10 C to 50C (14F to 122F)
Supported measuring units Specific gravity
Alcohol tables
Sugar extract tables
API functions
H SO tables
Ten programmable custom functions ( e.g. H O HCl CH O )
Sample volume 2 mL
Dimensions ( L x W x H ) 140 mm x 138 mm x 27 mm ( 5.5 in x 5.4 in x 1.0 in )
Data memory 1024 measured results
Power supply Two 1.5 V alkaline batteries
Weight 351 g (12.4 ounces) 396 g ( 14 ounces)
Interfaces IrDA OBEX LPT RFID
Intrinsically safe Ex II 2 G Ex ib IIC T4
Industries Chemical Industry Petroleum Industry
Electronics
Filling at higher temperatures possible
Viscosity 100 mPa s density 2 g cm
Sample must not freeze within the measuring cell
